6. Commissioning, operation
The following screen appears:
EN
Fig. 35 - Selecting the source "IN A"
Automatically the program shows the following screen and it remains in this position until the operator points out what type
of parameter he desires to associate to a selected channel, for example to the Channel A. In this case press [IN A] for
measuring from the input.
The main screen changes as follows:
3
Fig. 36 - Source "IN A" as first selection
The calibrator is now set on the IN A module, and it select the last used unit for this module (in this case the last used unit was
mV). Press the button indicated with to change the unit from mV to Tc and the following screen appears:
3
Fig. 37 - Selecting [mA] unit for module IN A
