6. Commissioning, operation
By pressing the letter button quickly activates the channel: the button displays a grey background when active.
1
EN
Fig. 12 - Changing the channel letter
By pressing and keeping pressed the button the following screen appears:
1
Fig. 13 - Selecting the channel letter
Press the [Channel C] button to assign the channel C.
The screen changes as follows:
2
Fig. 14 - First window assigned to channel "C"
Press the button ind
icated with to select the module for RTD measuring.
2
