6. Commissioning, operation
The programmable ramp follows the following profile:
Last point
EN
Points number
First point
Ramp time Soak time
Fig. 58 - Ramp profile
Keep pressed the button [RAMP ON] to set the ramp parameters:
Fig. 59 - Setting ramp parameters
The screen above shows a ramp with low range of 0 V, the value reach the high range of 10 V in 11 steps and after 20 seconds,
and the ramp runs for 2 cycles.
