3. Specifications
Case
Material
Ingress protection
Dimensions
Weight

3.2 Certificates

Certificate
Calibration
Recommended recalibration interval
Approvals and certificates, see website
Weitere technische Daten siehe WIKA-Datenblatt CT18.02 und Bestellunterlagen.

3.3 Pressure sensors

(other pressure ranges available on request)
One year specifications
■
Temperature effect: 0.002 % of reading * |t – t
■
Process connection: 1/4" BSP male
■
Measuring range
Relative pressure
-60 ... +60 mbar (-0.9 ... 0.9 psi)
-500 ... +500 mbar (-7.3 ... 7.3 psi)
-900 ... +1,500 mbar (-13.1 ... 21.8 psi)
0 ... 7 bar (0 ... 100 psi)
0 ... 21 bar (0 ... 305 psi)
0 ... 50 bar (0 ... 725 psi)
0 ... 100 bar (0 ... 1,450 psi)
0 ... 200 bar (0 ... 2,900 psi)
0 ... 400 bar (0 ... 5,800 psi)
0 ... 700 bar (0 ... 10,150 psi)
0 ... 1,000 bar (0 ... 14,500 psi)
Absolute pressure
0 ... 1,500 mbar abs. (0 ... 21.8 psi)
0 ... 2,500 mbar abs. (0 ... 36.3 psi)
0 ... 5 bar abs. (0 ... 72.5 psi abs.)
0 ... 7 bar abs. (0 ... 100 psi abs.)
0 ... 21 bar abs. (0 ... 305 psi abs.)
0 ... 81 bar abs. (0 ... 1,175 psi abs.)
0 ... 100 bar abs. (0 ... 1,450 psi abs.)
WIKA operating instructions, model Pascal ET
Front panel aluminium
IP54
305 x 210 x 90 mm (12 x 8.27 x 3.55 in)
approx. 3 kg (6 lbs 6 oz)
3.1 calibration certificate per DIN EN 10204
option: ACCREDIA calibration certificate
1 year (dependent on conditions of use)
| for t : 0 °C ≤ t ≤ 18 °C and 28 °C ≤ t ≤ 50 °C and t
c
32 °F ≤ t ≤ 64.4 °F and 82.4 °F ≤ t ≤ 122 °F and t
Precision (% FS)
0.1
0.015
0.015
0.015
0.015
0.015
0.015
0.015
0.015
0.025
0.025
0.015
0.015
0.015
0.015
0.015
0.015
0.015
= 20 °C
c
Accuracy (% FS) Resolution
0.15 0.001 mbar
0.025 0.001 mbar
0.025 0.01 mbar
0.025 0.1 mbar
0.025 0.1 mbar
0.025 1 mbar
0.025 1 mbar
0.025 10 mbar
0.025 100 mbar
0.05 100 mbar
0.05 100 mbar
0.025 0.01 mbar
0.025 0.01 mbar
0.025 0.1 mbar
0.025 0.1 mbar
0.025 0.1 mbar
0.025 1 mbar
0.025 1 mbar
EN
= 68 °F
c
(0.00001 psi)
(0.00001 psi)
(0.0001 psi)
(0.001 psi)
(0.001 psi)
(0.015 psi)
(0.015 psi)
(0.145 psi)
(1.45 psi)
(1.45 psi)
(1.45 psi)
(0.0001 psi)
(0.0001 psi)
(0.001 psi)
(0.001 psi)
(0.001 psi)
(0.015 psi)
(0.015 psi)
