1.8 TECHNICaL FEaTUrES
SPECIFICATION
Max. capacity of lift without pull system
Max. capacity with lifter equipped with pull system
Min. height
Max. height
Platform length (Fig. 2 -N°4)
Platform width
Base length (Fig. 2 -N° 8)
Base width
Total width with wheel support platforms
Wheel support platform width (Fig. 2 -N° 2 and 3)
Wheel support platform length
Operating pressure of lift hydraulic circuit
Operating pressure of pull arm pump hydraulic circuit
Operating pressure of pneumatic supply circuit
Weight of lift complete with accessories without pull system
Weight of standard pull arm with accessories
Weight of lift complete with accessories and pull system
Ascent time
Descent time
Three-phase power supply version
Single-phase power supply version
Power supply frequency
Three-phase electric motor power
Auxiliary circuit voltage with 400 V three-phase power supply
Auxiliary circuit voltage with 230 V single-phase power supply
Control unit weight
53
MEaSUrE VaLUE
kg 3000
kg 2800
mm 110
mm 1520
mm 3720
mm 770
mm 1900
mm 600
mm 1910
mm 570
mm 702
bar 290
bar 500
bar 8
kg 935
kg 172
kg 1107
sec 62
sec 81
V ac 400
V ac 230
Hz 50
kW 1,5
V ac 24
V dc 230
kg 50
