3-5. Service Setup
34. Pump maximum speed
Normally setting is not necessary.
Please adjust when need to reduce the pump sound etc.
Besides that, it has Air Purge function.
When *Pump fl ow setting is Max. Duty, this duty set is the fi x pump duty run
during room side operation.
35. Pump down
Operate pump down operation
36. Dry concrete
Operate concrete curing operation.
Select Edit, set temp for every stage (1~99 1 is for 1 day).
Setting range is 25~55°C
When it is turned ON, dry concrete starts.
When it is 2 zone, it dries both zones.
37. Service contact
Able to set name & tel no. of contact
person when there is breakdown
etc. or client has trouble. (2 items)
Initial setting: Depend on model
Service setup 12:00am,Mon
Pump down:
ON
Confi rm
30°C
Service setup
Service contact:
Contact 1
Contact 2
Select Confi rm
Service setup
Flow rate
88:8 L/min
Select
Service setup
Pump down operation
Pump down:
45°C
40°C 40°C
35°C
1 2 3 4 5
12:00am,Mon Contact-1: Bryan Adams
ABC/ abc
A B C D E F G H I J K L M N O P Q R
S T U V W X Y Z
j k l m n o p q r s t u v w x y z
Select
12:00am,Mon
Max. Duty Operation
Air Purge
0xCE
17:26, Wed
in progress!
ON
OFF
Confi rm
35°C
6
Stage
0-9/ Other
a b c d e f g h i
Enter
