Analogue Inputs - Endress+Hauser memo-graph Version II Betriebsanleitung

Visual data manager
Inhaltsverzeichnis

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 4
Illumination off after ...
Signal
Channel identifier
Engineering units
Decimal point
Range starting point
Range end point
Zoom start
64
• Rear illumination: Settings for switching off the screen rear illumination.
(Screen saver switching off increases the life of the rear illumination).
Switches the display off xxxx minutes after the last time a push button was used (rear
illumination is switched off). All further functions of the unit continue (green LED is on).
Operating any push button switches the illumination back on. "0000 min" = no switch
off.

Analogue inputs:

• Settings/limits of analogue values of the measurement points connected.
Each channel selectable. See "Connections/terminal layout".
Identifier of the measurement point connected to this channel.
10 character.
Input of the engineering units used by the measurement point connected to this input
(e.g. bar, °C, m3/h, ...). 5 character.
Selection of the number of decimal points required for the 4 digit measurement value
display.
Transmitters change the measured value into a standard signal.
Example: 0-14 pH from the sensor is changed to 4-20 mA. The range starting point is
therefore "0".
The same as range starting point. Here, however, the end value of the range must be
set up e.g. "14" on a transmitter with 0-14 pH.
If the total range of the transmitter is not to be displayed the lower starting value of the
"Zoomed" section can be set in this address (higher resolution is achieved using this
feature).
Example: Transmitter 0-14 pH, required display section 5-9 pH. Set up "5".
