9. Technical data
Technical data
(Continued)
Technical changes reserved
100
physical peak:
RS 485, Cable length 1000 m screened cable
Baudrate: 93.75 kBaud, fixed, alternatively 45.5 kBaud
Function "Bus-monitor" (no influence on the PROFIBUS system)
PROFIBUS DP
as with conventionally connected components:
connection
Presettable slave address data format (DP/V1 formats): Integer
(serial interface
8, Integer 16, Integer 32, Unsigned 8, Unsigned 16, Unsigned
rear mounted
32, Floating-Point (IEEE 754)
alternative
Functionality of the PROFIBUS measurement point is identical
to RS 422/485
to conventional analogue inputs.
interface)
Combined use of PROFIBUS and conventional measurement
points are possible (max. 16 points/unit)
PROFIBUS PA measurement point connection via PA/DP
segment coupler
10. Accessories
• RS232 interface cable for connection to the front mounted interface socket.
• RS232 interface cable for connecting the unit with a modem.
• RS 232 <-> RS 485 interface convertor
• External PCMCIA card reader for ATA flash memory cards
• Various application packages, e.g. Batch protocol programme, waste water
software, Tele-Alarm (text message on mobile telephone, pager and PC), etc.
If required please contact your supplier.
