Connection plan:
Attention:
Should there be a possibility of high energy transients on long signal cables it is
recommended that an overvoltage protector be connected.
Screened signal cables are recommended on the following:
• RTDs, thermo-couples, ranges <1 V.
• When using the serial interfaces.
Power supplies:
90...253 V power supply, 50/60 Hz
L:
Phase L
N:
Neutral N
PE:
Earth/protection cable
Analogue inputs:
The first character (x) of the three digit terminal number is the respective channel
number (1.. to 8..: channels 1 to 8, or A.. to H..: channels 9 to 16).
Current
x11
x12
x13
-
x14
+
Digital inputs on the power supply board:
91
Digital input 1
92
Digital input 2
93
Digital input 3
94
Digital input 4
95
Digital input 5
96
Digital input 6
97
Digital input 7
Digital inputs on the digital board (s)
Digital board I
191
Digital input 8
192
Digital input 9
193
Digital input 10
18...30 V power supply, 0/50/60 Hz:
L+:
+ power supply
(or alternating current)
L-:
- power supply
(or alternating current)
PE:
Earth/protection cable
Voltage/thermo-couple
+
-
Digital board II
391
Digital input 23
392
Digital input 24
393
Digital input 25
4. Installation/connection/setting up
RTD
A
a
Sense / cold junction
compensation
B
