4. Installation/connection/setting up
58
Digital board I
194 Digital input 11
195 Digital input 12
196 Digital input 13
197 Digital input 14
198 Digital input 15
199 Digital input 16
291 Digital input 17
292 Digital input 18
293 Digital input 19
294 Digital input 20
295 Digital input 21
296 Digital input 22
- Ground digital board I
Hint: If the auxiliary power supply is to be used for the digital inputs of the digital
boards, auxiliary power "-" must be connected to the "-" on the digital boards.
Auxiliary voltage for the digital inputs, not stabilised, max. 150 mA:
+ Auxiliary voltage approx. +24 V
- Auxiliary voltage ground
Relay outputs on power supply board:
(Factory settings, can be changed, see "Setting up unit - setting up parameter list -
service")
41 Relay 1, normally closed
42 Relay 1, common
44 Relay 1, normally open
53 Relay 2, Contact 1
54 Relay 2, Contact 2
63 Relay 3, Contact 1
64 Relay 3, Contact 2
73 Relay 4, Contact 1
74 Relay 4, Contact 2
83 Relay 5, Contact 1
84 Relay 5, Contact 2
Open collector output (NPN transistor):
98 Collector
99 Emitter
Relay outputs on digital board (s)
Digital board I
151 Relay 6, Contact 1
152 Relay 6, Contact 2
251 Relay 7, Contact 1
252 Relay 7, Contact 2
351 Relay 8, Contact 1
352 Relay 8, Contact 2
Digital board II
394 Digital input 26
395 Digital input 27
396 Digital input 28
397 Digital input 29
398 Digital input 30
399 Digital input 31
491 Digital input 32
492 Digital input 33
493 Digital input 34
494 Digital input 35
495 Digital input 36
496 Digital input 37
- Ground digital board II
Digital board II
751 Relay 12, Contact 1
752 Relay 12, Contact 2
851 Relay 13, Contact 1
852 Relay 13, Contact 2
951 Relay 14, Contact 1
952 Relay 14, Contact 2
