Chapter 4 Description of the labeler

Figure: Alpha Entry connections

DE DE
GB
FR FR
NL
IT
ES
RU
Spare
parts
Version: 23.04.2018
No. Designations
1 HMI DISPLAY
2 I/O INTERFACE
3 PRODUCT SENSOR
4
LABEL SENSOR
5 POWER SUPPLY IEC 320 C14
6 MAIN SWITCH
Page 22 of 76
Fig. 4-2: Connections behind the base plate on top of the housing
40059377 BTA Alpha Entry
ML-GB
