T
A Base frame
B Caster Steer-Lock knob
C Foot end
Foot end release handle (green)
D
Foot end release handle (red)
E
Hand grips
F
G Head end
Head end release handle (red)
H
Litter release button (blue)
I
J Litter retention brackets
Loading wheel
K
Release button (green)
L
Retractable base lifting handle (optional)
M
C C o o n n t t a a c c t t i i n n f f o o r r m m a a t t i i o o n n
Contact Stryker Customer Service or Technical Support at: 1-800-327-0770.
Stryker Medical
3800 E. Centre Avenue
Portage, MI 49002
USA
N N o o t t e e - - The user and/or the patient should report any serious product-related incident to both the manufacturer and the
Competent authority of the European Member State where the user and/or patient is established.
To view your operations or maintenance manual online, see https://techweb.stryker.com/.
Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical Support.
Include the serial number in all written communication.
EN 8
Y
U
V
R
AA
R
Y Z
X
W
Transport wheels
N
P Wheel locks
Retractable litter lifting handles
R
T Knee Gatch release levers
Knee Gatch lifting handle
U
V Roller wheel
Optional DIN retention pin
W
X Litter frame
Y Siderail release handle
Perimeter bumper
Z
AA Backrest
Backrest adjustment release handle
AB
AB
R
W
V
6100-109-005 Rev AA.0
