The Tech-Air System comes with three different Riding Modes that permit the use of the
®
System 1.) on public roads ("Street Mode"), 2.) on closed circuit race tracks ("Race Mode"),
and 3.) on off-road tracks ("Off-Road Mode"). Users can easily switch between these three
Riding Modes by clicking the Display Button (3a) or using the Tech-Air
WARNING! Street Mode operation differs from Race Mode and Off-Road Mode
and vice versa, always make sure to select the Street Mode when
riding on public roads.
3. Tech-Air
®
The "Envelope of Protection" is a term used to generally describe situations and/or
circumstances where the System may provide protection, denoted as "inside the Envelope",
and those where it will not provide protection, denoted as "outside the Envelope".
WARNING! No product can provide complete protection from injury (or death),
or damage to persons or property in the event of a fall, accident,
collision, impact, loss of control, or other event.
The System is equipped with an Airbag (11) that covers the areas shown in Figure 2,
protecting the motorcycle User who's wearing the System in the event of an accident or
other triggering events. There are limitations to the protection that the System can provide
as explained later in this User Manual (Section 4, "Limitations of Use").
(Front)
9 EN
Envelope of Protection
Figure 2: Area of Airbag (11) coverage
Area of
Airbag
coverage
(Back)
