Unit Description
4.5

Allocation of inputs and outputs to the measurement channels

Factory a fixed allocation of inputs and outputs is preset (see the following mapping
tables) for this device.
This assignment can be changed as needed.
See Ä Chapter 10.4 'Configuration' on page 143.

Connection overview

4.5.1

Assignment tables

Meaning
Analysis inputs
Analogue inputs
Digital input
Analogue outputs
Digital outputs

4.5.1.1 Versatronic Standard

Table for version ES, see
Measuring
channel Inputs and outputs Explanation
Drainage 1 IN 7 *
or alternatively
IN 6
PWR 24V
IN 1
IN 4
OUT 3
OUT 14 ****
or alternatively channel 2 OUT 14/15
OUT 4
Drainage 2 IN 8 **
or alternatively
417102269 Rev. 2-08.2020
Option boards
Base
Colour assignment
white
Bright yellow
dark yellow
light blue
dark blue
Ä Chapter 5.3 'Material code' on page 40
Input Measuring signal (analog input)
Input Measuring signal Standard signal input 1
Power supply Standard signal input 1
Input Enable input 1
Temperature input
Controller output 1 (changeover contact)
Controller output 2 (make contact)
Standard signal output
Input Measuring signal (analog input)
32
Option board
O
O
O
O
