Use
9.5

Using the data monitors / recording function

In the standard version of Ecolab ' Versatronic' equipped with a data monitor.
Used for recording and viewing analogue measurement data and signal states of binary
functions. There are 2 groups are available from which to record each up to 4 analogue
values and binary values 3 and may be in a line recorder chart. For each group, there is a
separate diagram in the control ring.
An extension of the data monitor is the registration function, which is available as an extra.
Ä Chapter 12.9.4 'Enable extra codes' on page 236.
See
The features of the data monitoring and registration function are shown in the following
table:
Feature / function
Measurement of data recording
Recording the readings of up to 4 analogue channels and display of
readings in line recorder representation
Binary data recording
Recording of binary values of up to 3 binary channels and display the
binary data as binary tracks chart
Show events
Entries in the event list will be displayed as an icon in a line recorder
chart
History function
Scroll down the line recorder chart to past measured data and events
Zoom function
View of measurement data archives for longer periods in a
compressed image section of the time period
Measurement data collection
With USB memory stick for archiving recorded measurement data and
evaluation with Ecolab PCC / PCA3000
417102269 Rev. 2-08.2020
Data monitor
98
Recording
X X
X X
X X
X
X
X
