Electrical connection
7.5.3

Base binary inputs

Plug /
terminal Connection option
IN 1 to 3 Binary input (floating contact) a
In the configuration of the binary input, set "Contact" to "Potential free contact".
Binary (external power
source)
In the configuration of the binary input of the "Contact" must be set to "external
power source".
Binary input (NPN transistor
switching output)
In the configuration of the binary input, set "Contact" to "Potential free contact".
Binary input (PNP transistor
switching output)
In the configuration of the binary input of the "Contact" must be set to "external
power source".
( 1 ) For the power supply of sensors with 24 V DC of the power supply output PWR is 24V available.
7.5.4

Base analogue outputs

Plug / terminal
OUT 4
OUT 5
417102269 Rev. 2-08.2020
Wire Potential
b
a
b
1
a ( )
b ( 1 )
c
d
1
a ( )
b ( 1 )
c
d
Connection option
analogue output DC 0 to 10 V DC or 0 (4) to 20 mA
(configurable)
analogue output DC 0 to 10 V DC or 0 (4) to 20 mA
(configurable)
56
Terminal
PWR IN 1
24V
Floating 28
contact
29
Logical signal 28
+
Logic signal - 29
Sensor + 42
sensor - 43
Switching 28
signal
(collector)
sensor - 29
Sensor + 42
sensor - 43
Switching 28
signal
(collector)
sensor - 29
Symbol
IN 2 IN 3
30 32
31 33
30 32
31 33
30 32
31 33
30 32
31 33
Symbol
