Device menu
( 1 ) The unit displayed depends on the operating mode. See
2
( ) The set temperature unit from the basic settings is displayed as a unit.

10.4.3.5 Analysis inputs configuration Cr / Ci

Analysis inputs: IN7, IN8, IN9, IN10 equipped with Cr or Ci plug-in card
Go to: Device menu è Configuration è Analogue inputs è Analysis input 1 to 4 è
Configuration
Configuration
item
Name
Manual
compensation
Compens.- Temp.
Man.
Compensation
temperature
Reference
temperature
Filter time constant 0.0 to 25.0 s
1
( ) The set temperature unit from the basic settings is displayed as a unit. ø "Basic settings"
417102269 Rev. 2-08.2020
Selection / option
Up to 15 characters of text
Yes
No
Alias values/
Alias value 1: Ch.1 reading
Alias value 2: Ch.1 Temp.
AliasValue 3: Ch.2 reading
* Alias value 4: Ch. 2 Temp.
Alias Value 5: Ch.3 reading
* Alias value 6: Ch. 3 Temp.
AliasValue 7: Ch.4 reading
* Alias value 8: Ch. 4 temp.
* = Please select only the
highlighted points
1
0 to 99999 ( )
1
0 to 99999 ( )
156
Ä Chapter 10.4.2 'Basic settings' on page 148.
Explanation
Input name
Yes = manual temperature
compensation (fixed stored value)
No = automatic temperature
compensation (reading)
Source of compensation
temperature with automatic
compensation
Value for man. Compensation
temperature
Reference temperature for manual
temperature compensation
Optimise reading refresh:
The larger the value of the filter time
constant, the slower is the
measured value display.
Default
IN7: Channel 1
Cr / Ci
IN8: Channel 2
Cr / Ci
IN9: Channel 3
Cr / C IN 10: Ch. 4
Cr / C
No
IN7: Alias Value 2:
Channel 1
temperature
IN8: Alias Value 4:
Channel 2
temperature
IN9: Alias Value 6:
Channel 3
temperature
IN 10: Alias value
8:
Channel 4
temperature
1
25,0 ( )
1
25,0 ( )
5.0 s
