10.4.3.2 Universal inputs Configuration

Universal input base: IN 6
Universal inputs option board: IN 11/12
Call: Device menu èConfiguration èanalogue inputs èUniversal input 1 to 3
èConfiguration
Configuration
point
Name
Timer
Signal
Unit
Initial scale
End of scale
Point format
Filter time constant 0.0 to 25.0 s
manual
compensation
(Free only mode
chlorine)
Compensation
Temp.
(Free only mode
chlorine)
Man.
Compensation
temperature
Compensation pH
(Free only mode
chlorine)
Alarm 1
Selection/configuration
up to 15 characters of text
linear scaling,
Temperature measurement,
free chlorine T-compensated
pH /
0 to 20 mA
4 to 20 mA
20 to 0 mA
20 to 4 mA
up to 5 characters of text
(1)
-99999 to +99999
(1)
-99999 to +99999
Auto,
XXXXX
XXXX.X
XXX.XX
XX.XXX
X.XXXX
Yes
No
Alias values /
AliasValue 1: Ch.1 reading
* Alias Value 2: Kan.1 Temp.
Alias Value 3: Ch.2 reading
* Alias Value 4: Kan.2 Temp.
Alias Value 5: Ch.3 reading
* Alias Value 6: Kan.3 Temp.
Alias Value 7: Ch.4 reading
* Alias value 8: Ch. 4 Temp.
* = Please select only the marked points
2
0 to 99999 ( )
Manual values/
* Manual control 1
Manual control 2
Manual control 3
....
* = Please select only the marked points
151
Explanation
Designation for receipt
Type of measurement
Linear scaling:
For probes with 0 / 4-20 mA output
Temperature measurement:
For temperature sensor PT100 or
PT1000
Free chlorine:
Cl sensors (Temp and pH compens.
necessary)
Output of the connected sensor
Enter the desired unit to be
displayed.
Assign a value of 0/4 mA for the
analogue output.
Assign a value of 20 mA for the
analogue output.
Determination of decimal places in
the measured value display
Optimisation of the measurement
value The larger the value of the
filter time constant, the slower the
measured value is displayed.
Yes = manual temperature
compensation (fixed stored value)
No = automatic temperature
compensation (measured value)
Determining the source of the
compensation temperature with
automatic compensation
Value for man. Temperature
compensation
Determining the source of the
compensating pH at automatic
compensation
417102269 Rev. 2-08.2020
Device menu
Default
IN6: Ch.1 Pa
IN11: Ch.3 Temp.
IN12: Kan.2 Temp.
IN6: linear scaling
IN11: Temperature
IN12: linear
scaling:
4 to 20 mA
mg / l
1
0,0000 ( )
IN6: 2000,0
IN11: 100,00
IN12: 2000,0
XXXX.X
1.0 sec
No
IN6: Alias Value 2:
Ch. 1 Temp
2
25,0 ( )
Manual value 1
(pH 7)
