10.4.1.2 Calibration timer

Call calibration timer Configuration universal inputs:
Device menu è Configuration è Analogue inputs è Universal input 1 to 3 è Calibration
timer
Call calibration timer configuration analysis inputs:
Device menu è Configuration è analogue inputs è Analysis input 1 to 4 è Calibration
Configuration item Selection / option Explanation
Function
Alarm / event list
Alarm text
Calibration interval
Inactive Activation/deactivation of an analogue input
Active calibration timer
OFF Expired calibration timer assigns the
Alarm notification to an alarm list or event list
Event
21 characters of text Message text for the alarm/event list with
lapsed calibration timer
0 to 99999 days Period from resetting the calibration timer by
successful calibration up to the end of the
calibration timer
147
Device menu
Default
Inactive
Event
Ch. X
calibration
command
10
