Temperature measurements
Energy measurements
Energy measurements are only available on the RVT12-3P (the 3 phase model is equipped with a real time clock).
Energy values may be "Reset" to 0.
4.2.3.

Waveform

Available voltage and current signals (depending on RVT type and connection used) and the line current can be dis-
played on the screen as waveforms.
STATUS
Approved
Figure 21 shows the voltage wave form between line and neutral.
SECURITY LEVEL
Public
PO WER FACTO R CON TR O LL ER RV T
Reset energy
values
DOCUMENT ID
9AKK107045A9645
REV. LANG. PAGE
D en 37/542
