By clicking the
stand and set the parameters easily. Following screen will appear after click the question mark on the
screen:
Clicking the Red Cross button at the right end of the title bar
Note: The RVT returns automatically to AUTO mode when the touch screen is not touched for more than five minutes.
3.2.3.

Setting area

The setting area consists of buttons, setting and information fields. After finishing the setting on one screen, the OK
button shall be clicked to valid the settings. In case there are more settings which cannot be displayed in
one screen, the arrow button
will show in next screen.
3.2.4.

Status bar

The status bar displays current active capacitor steps and the RVT status. The meaning of the status icons can be
found in 3.2.1.
Hardware and software lock
RVT has both hardware and software lock. A hardware switch in blue color is located at back of the controller. When it
is pressed, the RVT is locked and the icon
switch is released, the same icon will turn into:
and the commissioning (both guided and auto) is disabled as well.
The icon means the RVT bank settings are locked by software. The icon
are unlocked by software. When the controller is locked by software, all the banking settings are protected, i.e. they
are not accessible.
Description of soft lock can be found in
3.2.5.

Keyboard entry screen

All data will be entered through a keyboard interface.
STATUS
Approved
question mark, a piece of relevant help information will display to aid the operator to under-
Figure 16: RVT help information
will appear in the screen. By clicking the arrow button, the remaining settings
will appear on the status bar at the bottom of the display. When the
4.3.1.1.
SECURITY LEVEL
Public
the current active screen will be closed.
,
. If the RVT is locked, then all bank settings are not accessible
DOCUMENT ID
9AKK107045A9645
PO WE R FACTO R CON TR O LL ER RV T
Figure 15
means the RVT bank settings
