Nr. Bedeutung
31102 67-TOC-4 InRush picked
up (67-TOC-4 InR.PU)
31103 >BLOCK 67N-TOC-1 (>BLK
67N-TOC-1)
31104 67N-TOC-1 picked up
(67N-TOC-1 PU)
31105 67N-TOC-1 TRIP (67N-
TOC-1 TRIP)
31106 67N-TOC-1 Time Out
(67N-TOC-1 T. O.)
31107 67N-TOC-1 is BLOCKED
(67N-TOC-1 BLK)
31108 67N-TOC-1 InRush picked
up (67N-TOC-1InR.PU)
31109 >BLOCK 67N-TOC-2 (>BLK
67N-TOC-2)
31110 67N-TOC-2 picked up
(67N-TOC-2 PU)
31111 67N-TOC-2 TRIP (67N-
TOC-2 TRIP)
31112 67N-TOC-2 Time Out
(67N-TOC-2 T. O.)
31113 67N-TOC-2 is BLOCKED
(67N-TOC-2 BLK)
31114 67N-TOC-2 InRush picked
up (67N-TOC-2InR.PU)
31115 >BLOCK 67N-TOC-3 (>BLK
67N-TOC-3)
31116 67N-TOC-3 picked up
(67N-TOC-3 PU)
31117 67N-TOC-3 TRIP (67N-
TOC-3 TRIP)
31118 67N-TOC-3 Time Out
(67N-TOC-3 T. O.)
31119 67N-TOC-3 is BLOCKED
(67N-TOC-3 BLK)
31120 67N-TOC-3 InRush picked
up (67N-TOC-3InR.PU)
31121 >BLOCK 67N-TOC-4 (>BLK
67N-TOC-4)
SIPROTEC Compact, 7SC80, Handbuch
E50417-G1100-C486-B2, Ausgabe 09.2018
Funktion Info Meldespeicher
-Art
ger.U/AMZ AM * k g
ger.U/AMZ EM * *
ger.U/AMZ AM * k g
ger.U/AMZ AM * k
ger.U/AMZ AM * *
ger.U/AMZ AM k g k g
ger.U/AMZ AM * k g
ger.U/AMZ EM * *
ger.U/AMZ AM * k g
ger.U/AMZ AM * k
ger.U/AMZ AM * *
ger.U/AMZ AM k g k g
ger.U/AMZ AM * k g
ger.U/AMZ EM * *
ger.U/AMZ AM * k g
ger.U/AMZ AM * k
ger.U/AMZ AM * *
ger.U/AMZ AM k g k g
ger.U/AMZ AM * k g
ger.U/AMZ EM * *
Funktionen, Parameter, Informationen
Rangierbarkeit
* LED REL
* LED BE REL
* LED REL
m LED REL
* LED REL
* LED REL
* LED REL
* LED BE REL
* LED REL
m LED REL
* LED REL
* LED REL
* LED REL
* LED BE REL
* LED REL
m LED REL
* LED REL
* LED REL
* LED REL
* LED BE REL
F.3 Informationsübersicht
