Siemens SIPROTEC Compact 7SC80 Handbuch Seite 119

Adr. Parameter
1353 51N-4 Drop-out
1354 51N-4 IEC Cur.
1355 51N-4 T adder
1356 51N-1 ANSI Cur.
1357 51N-1 Rec. Cur.
1358 51N-2 ANSI Cur.
SIPROTEC Compact, 7SC80, Handbuch
E50417-G1100-C486-B2, Ausgabe 09.2018
C Einstellmöglichkeiten
sofort
Disk emulation
Nein
Invers
Stark invers
Extrem invers
Langzeit invers
0.00 .. 30.00 s
Nein
Very inverse
Inverse
Short inverse
Long inverse
Moderately inv.
Extremely inv.
Definite inv.
Nein
Kurve 101 (A)
Kurve 102 (1)
Kurve 103 (17)
Kurve 104 (N)
Kurve 105 (R)
Kurve 106 (4)
Kurve 107 (L)
Kurve 111 (8*)
Kurve 112 (15)
Kurve 113 (8)
Kurve 114 (5)
Kurve 115 (P)
Kurve 116 (D)
Kurve 117 (B)
Kurve 118 (M)
Kurve 119 (14)
Kurve 120 (Y)
Nein
Very inverse
Inverse
Short inverse
Long inverse
Moderately inv.
Extremely inv.
Definite inv.
Voreinstellung Erläuterung
Disk emulation Drop-Out Characteristic
Invers 51N-4 IEC Curve
0.00 s Constant time adder 51N-4
Nein 51N-1 ANSI Curve
Nein 51N-1 Recloser Curve
Nein 51N-2 ANSI Curve
