Storage Indicators

The status of the storage media slots can be seen on the bottom toolbar of the main display.
These icons display the number, name, progress bar and status of the SD card and active media
2 slot which could be an USB Drive, external network location or the optional M.2 SSD when set
to 'network storage'.
Number
Drive '1' shows the SD card slot on the front panel. Drive '2' shows the active media for the
second slot. This could be any external drive connected via the 'ext disk' USB-C port on the
rear, external network location or the optional M.2 SSD if it is set to 'network storage'.
TIP If you are using a drive hub you can connect multiple drives via the 'ext disk'
connector on the rear. In this case the second drive icon will only display the
active drive.
Name
and is especially helpful if you are using the Blackmagic MultiDock in order to make sure you
are playing or recording to the correct drive. For network locations, it will be the name of the
network folder you have connected to. For the internal 'network storage' function 'M.2 SSD'
will appear.
The text to the right of the number is the name
of the SD card, USB drive, network location or
M.2 SSD when recording internally. For SD cards,
USB drives and external SSDs, this will be the
name you selected when formatting the storage
Storage Media 80
