Blackmagic Design HyperDeck Shuttle HD Installations- Und Bedienungsanleitung Seite 103

2 A window will appear prompting you to enter a common name and subject alternative name
for the HyperDeck. Adjust any other details as required using the table below.
Information
Common Name
Subject Alternative Name
Country
State
Location
Organization Name
3 Once you have filled in the certificate details, press 'generate'.
When you generate a .csr you will also be creating a public key and private key at the same
time. The public key will be included with the signing request while the private key will remain
with the unit. Once the CA or IT department have verified the information in the CSR with your
organization, they will generate a signed certificate with the above details along with your
public key.
Once imported, the HyperDeck Shuttle will use the public and private key to confirm the
identity of the HyperDeck and to encrypt and decrypt data share via HTTPS or via HyperDeck
Ethernet Protocol when using an SSL program.
Importing a signed certificate:
1 Click on 'import signed certificate'.
2 Navigate to the location of the signed certificate using the file browser and once the file is
selected click on 'open'.
The domain, issuer and valid until fields will update with the information from your CA.
Generally, a signed certificate will be valid for about a year so the process will need to be
repeated as you reach the expiration date.
Since a domain name was selected, you will need to speak to your IT department about
resolving the DNS entry for the HyperDeck Shuttle unit. This will point all traffic for the IP
address of the HyperDeck Shuttle to the selected domain address in the signing request.
Description
The domain name you will use
An alternate domain name
Country for your organization
Province, region, county or state
Town, city, village etc. name
Name of your organization
Example
hyperdeck.melbourne.com
hyperdeck.melbourne.net
AU
Victoria
Port Melbourne
Blackmagic Design
Blackmagic HyperDeck Setup 103
