Status Text
You can turn status text on or off for each monitor output. On the LCD turning status text off will
remove the lower toolbar from view. You can also do this by swiping the touchscreen down. On
the SDI and HDMI monitor outputs turning status text off will remove both the top and bottom
text. More information on the monitor output can be found in the 'status text overlay' section
later in this manual.
Anamorphic De-squeeze
The anamorphic de-squeeze option allows you to correctly display horizontally squeezed
images from any anamorphic sources, such as digi-beta tapes containing anamorphic 16:9
content or anamorphic lenses. Tap 'none' for non anamorphic sources.
Focus Assist Color
When you are using colored lines for focus assistance on your LCD display or monitor out, you
can select your preferred color for the lines from red, blue, white or green. Changing the color
can help to make your area of focus stand out more.
Focus Assist Type
There are two focus assist modes, 'peaking' and 'colored lines'.
Peaking When you select focus peaking the areas within your frame with the highest contrast
will be highlighted.
Colored Lines If colored lines is selected, lines will be super imposed over any part of the image in
focus. This can be a more visually intrusive than using 'peak'.
