Progress Bar - Blackmagic Design Hyperdeck Shuttle Hd Installations- Und Bedienungsanleitung

Storage Media Status
The storage indicators display the name and status of the connected storage. The first indicator
displays the SD card slot. The second indicator displays the selected external disk, M.2 SSD
or network location when connected. If you are using a USB hub or dock such as Blackmagic
MultiDock 10G the current drive will be displayed.
HyperDeck
Shuttle 4K Pro
Disk or Drive Indicator
The text above the progress bar indicates the media slot.

Progress Bar

The progress bar icon will be either blue, white or red depending on its current status and will
display the used space on the card.
Text underneath the progress bar will display either the record time remaining or the status
of the slot.
Time remaining
When your storage media has space remaining, the duration available will be displayed in
hours:minutes:seconds based on the current source standard and your chosen codec and
quality settings. If there is less than an hour left, minutes:seconds remaining will be displayed.
SD slot in use
The blue drive icon indicates the active drive. This is the drive that will be
used for playback and recording.
A white drive icon indicates there is media present, but not active. A solid
white icon indicates the media is full.
The bar will illuminate red during recording.
Selected network
storage, external disk
or network location
Using the Monitor Output 72
