Blackmagic Design HyperDeck Shuttle HD Installations- Und Bedienungsanleitung Seite 23

Drop Frame
For NTSC sources at frame rates of 29.97 or 59.94, you can select 'drop frame' or 'non-drop
frame' timecode. If the source is unknown, select 'default'. This will maintain the standard of the
input, or default to drop frame if there is no valid timecode.
Preset
You can set your timecode manually by pressing the set button and entering the start timecode
using the search dial and set button. Make sure the 'preset' option is selected under the
input menu.
Output
Select your timecode options for your outputs.
To output a continuous timecode for all clips recorded on a card or drive,
Timeline
select timeline.
Clip Selecting the clip option will output the timecode of each individual clip.
File Settings
Filename Prefix
When first set up, your HyperDeck Shuttle HD will record clips to your SD Card or USB flash
disk using the following filename convention.
HyperDeck_0001
HyperDeck_0001
HyperDeck_0001
You can change the filename prefix via the HyperDeck Setup utility. For more information, refer
to 'Blackmagic HyperDeck Setup' later in this manual.
Prefix
Clip Number
Settings 23
