NOTE When playing from a network volume, HyperDeck Shuttle HD assumes guest
login on the server. Server access that requires a login and password is not currently
supported using the menu and set buttons but you can enter credentials using REST
API or HyperDeck Ethernet Protocol.
USB Spill
If you are using a Blackmagic MultiDock 10G or similar to connect more than one drive via the
'ext disk' usb connection, turning USB spill on will ensure that recording will spill from one
external disk to the next.
Format Media
SD cards and media connected via the rear ext disk connection can be formatted directly on
the unit or via a Mac or Windows computer.
Preparing Media on HyperDeck Shuttle HD:
1 Using the search dial and set button, select format media.
2 Select the media to format from the list and press set.
3 Choose the format and press set.
4 A confirmation window will appear detailing which card is to be formatted and the selected
format option. Select format.
5
A formatting window will appear once completed. Select OK.
HFS+ is also known as Mac OS X Extended and is the recommended format as it supports
'journaling'. Data on journaled media is more likely to be recovered in the rare event that your
storage media becomes corrupted. HFS+ is natively supported by Mac. exFAT is supported natively
by Mac and Windows without needing any additional software but does not support journaling.
To format media on a Mac or Windows computer, refer to the 'formatting media' section.

Setup Menu

The setup menu contains settings including language selection and default standard as well as
sections for the menu display, network settings and timecode options.
Settings 18
