Protocol
Blackmagic HyperDeck is shipped set to DHCP, so once connected, your network server will
automatically assign an IP address and no other network settings will need to be adjusted. If
you need to set a manual address, you can connect via a static IP.
With 'protocol' selected press the 'set' button to access the menu, scroll to 'Static IP' and
press 'set'.
IP Address, Subnet Mask, Gateway, Primary DNS and Secondary DNS
Once Static IP is selected, you can enter your network details manually.
To change the IP address:
1 Use the search dial to highlight 'IP address' and press the 'set' button on your HyperDeck's
control panel.
2
Using the search dial, adjust the IP address, rotate the search dial to adjust your IP address,
pressing 'set' to confirm before adjusting the next set of values.
3 Press 'set' to confirm the change and move to the next value.
When you have finished entering your IP address, you can repeat these steps to adjust the
Subnet Mask and Gateway. Once finished, press the 'menu' button to exit and return to the
home screen.
Timecode Settings
Set your timecode input and output options, including choosing between recording the source
timecode, time of day timecode or setting your timecode manually.
Input
There are four timecode input options available when recording.
Selecting video input will take the embedded timecode from HDMI sources with
Video Input SMPTE RP 188 metadata. This will maintain sync between your HDMI source and
the file recorded on the HyperDeck Shuttle HD.
Internal Use this option to record time of day timecode via the built in timecode generator.
By selecting 'last clip regen' for your timecode input, each file will start one frame
Last Clip
after the last frame of the previous clip. For example, if your first clip ends on
Regen
10:28:30:10, the next clip timecode will start at 10:28:30:11.
If you want to set a timecode manually, select the preset option. Recorded clips will
Preset
start at the timecode set via the 'preset' setting as shown later in this section.
