Selecting 'network storage' will let you record internally to the M.2 SSD. When you start
recording, these growing files are immediately accessible over the network so multiple users
can start editing right away in DaVinci Resolve. This eliminates any need to copy media from
SD cards or external USB disks. More information on accessing the internal recordings over the
network is later in this manual.
When 'record cache' is selected you can record high resolution video to slower and lower cost
media, such as SD cards. This lets you record at higher resolutions without needing the most
expensive media. It also ensures your recordings are intact if there are problems with your
media. For instance, you might be recording in a remote location without network access and
you need to make sure your media doesn't fail.
To disable the M.2 SSD, tap the 'none' option.
3G-SDI Output
Some broadcast equipment can only receive level A or level B 3G-SDI video. To maintain
compatibility, tap either 'level A' or 'level B'.
Remote
Select 'remote' to enable remote control via RS-422, this will let the HyperDeck be controlled
remotely by another device, for example, HyperDeck Extreme Control. Deselect remote to
control the unit locally. It's worth noting that while you cannot use HyperDeck Shuttle 4K Pro as
a controller, it can be controlled by a HyperDeck Pro or Plus model.
Setup Page 6
The last setup page contains settings for HDR format override, calibrating the LCD and
performing a factory reset.
