Tech nical Spec ifi ca tions
Power Require ments
100/120 ±10% VAC
220/240 ±10% VAC
50/60 Hz, 330 VA
Fuses
External
Internal
Mother Board:
High Voltage Power
Supply Board:
RF Amplifier Board:
Output Wave form
Coag u late: Damped Ape ri odic, cen tered at 1 MHz
Cut: Sinu soidal, 1 MHz
Output Power Range
Coag u late (20 set tings):
Micro Cut (10 set tings):
Cutting (6 set tings):
Output Setting Indi ca tors
Visual: Three-digit indi ca tors, except micro cut, which is two-digit
Aural: Voice annun ciator (synthe sizer)
Power Con trols
AC: ON/OFF Switch
RF Output: Panel mounted three-position rocker types
Panel Con nec tors
Bipolar: Two high voltage jacks
Cooling
Con vec tion; no fan
Weight
8.60 kil o grams
Dimen sions
33.5W x 22H x 40D cen ti me ters
Minimum Oper ating Tem per a ture
50°F (10°C)
Oper a tional Per for mance
The MALIS CMC-III Bipolar Elec tro sur gical System can be tested for oper-
a tional per for mance using 50 ohm and 400 ohm non in duc tive test loads
and RF ammeter or equiv a lent elec tro sur gical ana lyzer. A test setup is
shown in Figure 7 with typical values for each power setting. Use test
leads approx i mately 45 cm (18 in) long. These are typical values and output
power can vary depending on the line voltage, load resistor tol er ances, and
meter accuracy.
CODFR08059xx01v05.indd 9 CODFR08059xx01v05.indd 9
100/120 V Input: Two 3.15 Amp
Type T 250 VAC
220/240 V Input: Two 1.6 Amp
Type T 250 VAC
Two (F600, F601) 1.6 Amp
Type T 250 VAC
F400: 4.0 Amp Type T 250 VAC
F401: 4.0 Amp Type F 250 VAC
F500: 0.25 Amp Type T 250 VAC
.72–50 watts into 50 ohm noninductive
resistor load
.72–16.8 watts into 50 ohm noninductive
resistor load
20–120 watts into 400 ohm noninductive
resistor load

Power Output Charts

Typical Output vs. Power Setting
Coag Output into 50 ohms using 45 cm leads
(For ref er ence only)
Power Setting Output Current
(Malis Units) (RF amp)
0
8
10
15
20
25
30
35
40
45
50
60
70
80
90
100
110
120
130
140
150
Typical Output vs. Power Setting
Micro Cut Output into 50 ohms using 45 cm leads
(For ref er ence only)
Power Setting Output Current
(Malis Units) (RF amp)
0
8
10
15
20
25
30
35
40
45
50
9
Output Power
(Watts)
0.00 0.0
0.12 0.7
0.15 1.1
0.18 1.6
0.24 2.9
0.32 5.1
0.38 7.2
0.43 9.3
0.48 11.5
0.53 14.1
0.58 16.8
0.62 19.2
0.66 21.3
0.69 23.3
0.71 25.2
0.76 28.9
0.80 32.0
0.84 35.3
0.89 39.6
0.95 45.1
1.00 50.0
Output Power
(Watts)
0.00 0.0
0.12 0.7
0.15 1.1
0.18 1.6
0.24 2.9
0.32 5.1
0.38 7.2
0.43 9.3
0.48 11.5
0.53 14.1
0.58 16.8
