mAnAging therApy AnD DAtA
MaNaGING THeRaPY aND DaTa
Managing therapy Settings
DeVilbiss DV5X series CPAPs and SmartLink™ Therapy Management provide you with a wide variety of therapy setting options. Full details on the
®
options and their default settings are listed in the
CPAP itself or set them in the SmartLink software and then transfer them to the CPAP using a data card.
To manually set therapy parameters on the CPAP , follow the instructions in the DV51 or DV54 Set-Up Guides. Verify that the settings match those in the
SmartLink software study record.
to set therapy parameters in SmartLink software and then transfer the new settings to the CPAP using a data card:
1. Insert the card reader into a USB port on the computer running SmartLink software and insert a data card in the reader.
2. Select the appropriate table in the Patients menu.
3. Select 'View/Edit Study Details' from the Options menu for that patient.
4. Enter the desired changes in the Therapy Settings tab, the Device Settings tab or, for the AutoAdjust device only, the Respiratory Event Detection
tab. Views of these study tabs and their default settings are available in the Appendix.
5. Click the SAVE button to transfer the changes to the data card and to save them in the software.
• If the transfer is successful, the software will enter a System Note in the patient record:
programmed with updated settings. Verification of settings is pending.
notE
– Verification of the setting change will be noted on the card and entered in the patient record during the next transfer of therapy data to
the software. The patient note includes the success of the setting change with the date.
• If a blank data card is inserted into the card reader, a message appears:
settings update with buttons showing the removable drives; ex: H:\ (SMARTLINK). Click the drive where the blank data card is installed.
• If the Data card contains data that has not been downloaded yet, a warning appears:
data. Please try a different card or read the card before proceeding. Please insert a SmartLink
data card for settings transfer.
• Insert a different card and click OK to save the new settings to the data card and download the unread data later OR
• Click 'Cancel' and download the unread data before saving the settings to the data card. Then repeat steps 2-5 to save the settings changes.
6. Insert the data card into the SmartLink Module attached to the patient's CPAP . The CPAP will display one of the following messages:
• Card Detected, Please Wait...
the software, the module itself may contain new therapy management data that it needs to transfer to the data card.
•
Card Transfer, Successful
to the card. The data card can be removed or it can remain in the module to collect new therapy data as it becomes available from the CPAP .
notE
– If the module contained new therapy study information, that data was transferred to the card after the new settings were
transferred to the module and CPAP.
Appendix – Therapy Setting Options and
indicates that the module is attempting to transfer data. In addition to the setting changes sent from
indicates that new data on the card transferred to the module and new data on the module transferred
Defaults. You can set therapy parameters manually on the
SmartLink data card has been
Please select the SmartLink data card for
The inserted card contains unread
