EN

PaRTS

DV5M SmartLink Module
DV5SS SmartLink Software Kit (CD with software & manual, USB extension cable, SD card, card reader)
DV5FC-10 SmartLink Data Card (10 pack)
DV5FC-1 SmartLink Data Card (single)
DV5CR SmartLink Card Reader
DV51D-694 USB Extension Cable
DV5M-697 Oximeter Kit (oximeter and 25-use finger probe)
8000AA Oximeter Finger Clip Sensor
8000Q Oximeter Ear Clip Sensor
9054D-699 Nonin ® nVISION
A-DV5M SmartLink Module Instruction Manual
A-DV5SS SmartLink Clinical Software Instruction Manual

SPeCIfICaTIoNS

DeVilbiss SmartLink™ Module
®
Size ...................................................................................................................... 3.9" H x 3.1" W x 1.4" D (9.9cm H x 7.9cm W x 3.6cm D)
Weight ................................................................................................................................................................................... 0.30 lbs. (0.14 Kg)
Electrical Rating
Power Consumption Max (SmartLink module alone) ............................................................................................................................ 4 Watts
Voltage and Current .................................................................................................................................................. Power supplied by CPAP
Class II Equipment; Type BF Applied Parts; Continuous Operation
operating Conditions
Temperature Range ............................................................................................................................................... 41°F to 104°F (5°C to 40°C)
Humidity Range .................................................................................................................................................0 to 95% R.H. non-condensing
Atmospheric Pressure Range ............................................................................................................................... Sea level to 9,000' (2.743 M)
transportation and Storage Conditions
Temperature Range: ...................................................................................................................................... -40°F to 158°F (-40°C to +70°C)
Humidity Range: ................................................................................................................................................0 to 95% R.H. non-condensing
DeVilbiss SmartLink™ Desktop Software Specifications
Operating System ........................................................................................................ Microsoft
Adobe Reader ............................................................................................................................................................................6.0 or greater
® ®
RAM .......................................................................................................................................................................................512 MB or greater
Hard Drive Free Space ........................................................................................................................................................................... 150 MB
Hardware: .............................................................................................................SD Memory card reader supporting FAT16 file format OR
24 A-DV5SS
® Software
pArtS / SpecificAtionS
Windows XP
®
Microsoft Windows Vista
®
service pack 2 or higher OR
™
service pack 1 or higher
™
USB port for auxiliary card reader
