troubleShooting

TRoUbleSHooTING
The DeVilbiss SmartLink Module has no serviceable parts.

Software

Problem
Software Installation
problems
Software does not start
Software locks up
Data Card is not found by
software
Data Card found by
SmartLink software but did
not download

Module

Problem
CPAP does not recognize
attached module
CPAP does not recognize
inserted data card when
inserted into the module card
slot.
Card error on LCD
Settings error on LCD
Setup required message on
LCD
Oximeter data (SpO2 and
PR) not displayed.
CPAP is not fully functional.
Probable Cause
Computer does not meet
minimum requirements.
Windows Vista firewall blocking
SmartLink software from running.
Computer does not meet
minimum requirements.
Not enough system resources to
run SmartLink software.
Data Card is corrupt.
Data card is blank, no new data.
No new data has been copied from
a SmartLink Module.
Probable Cause
The CPAP is not connected to a
power source.
Module is not fully engaged to the
CPAP .
Card not oriented properly.
Card not fully inserted in the
module card slot.
Module is not fully attached to the
CPAP .
Wrong card type.
Card removed during data transfer. Card must not be removed during data transfer. Data transfer interruption may
Card corrupt or faulty.
Card removed during data transfer. Card must not be removed during data transfer. Data transfer interruption may
Card corrupt or faulty.
Module not setup properly.
Oximeter not properly connected
to the SmartLink module.
Oximeter probe not properly
attached to user.
Module may be defective.
Remedy
Make sure computer meets minimum system requirements of memory, hard disk
space, and operating system listed in Software Installing and Uninstalling section.
After installing on Windows Vista, SmartLink needs to be opened once by the
Administrator to allow it to run.
Make sure computer meets minimum system requirements of memory, hard disk
space, and operating system listed in Software Installing and Uninstalling section.
Close other Windows programs to free system resources.
Use new data card.
Data Card is OK, send to patient to download data from SmartLink Module.
Data Card is OK, send to patient to download data from SmartLink Module.
Remedy
Connect the CPAP to an appropriate power source and verify that the module is
recognized.
Remove the module from the CPAP , realign the primary data connector with the
circular connector of the CPAP , and press firmly until the module is locked into
position.
Reference the symbol on the top of the module for proper card orientation.
Press the card fully into the card slot until the card clicks into position.
Remove the module from the CPAP , realign the primary data connector with the
circular connector of the CPAP , and press firmly until the module is locked into
position.
Only use DeVilbiss SmartLink Data Cards. The card must be an SD card with
FAT16 format.
corrupt the card and prevent the card from working correctly. Reinsert card and
allow data transfer to continue until completed.
Return card to provider for replacement.
corrupt the card and prevent the card from working correctly. Reinsert card and
allow data transfer to continue until completed. If this error is not corrected,
contact provider for resolution.
Return card to provider for replacement. If this error is not corrected, contact
provider for resolution.
Notify provider of the situation and follow provider instructions.
Verify connection between the oximeter connector and module oximeter
connection port.
Reference the operating instructions that came with the Oximeter.
Remove the module from the CPAP and verify that the CPAP is fully functional. If
it functions properly without the module connected, the module may be defective.
Contact provider. If it still is not fully functional, consult the CPAP instruction guide
for troubleshooting.
