L1 Rib
Instructions for Use
CB3 screw guide
If the adjustable Tri color depth gauge is showing the color yellow, the screw must be inserted using the
screw guide:
CB3 screw guide 24-015-59-07
Screw i nsertion with Thumb Twist Screwdriver handle a nd
bl a de with CB3 Screw Guide.
To l oa d the screwdriver blade into the driver, retract the collar
a nd fully insert the hexagonal blade. Release the collar a nd
ens ure the blade is s ecurely s eated. The collar s hould return to
the fl ush position if the blade is fully i nserted.
Pl a ce the Screw Guide over the plate to ensure the screws
enter the plate at the correct a ngle a nd orientation. Using the
Thumb Twist Screwdriver select 7 mm s crews (with minimum
ri b thi ckness determined i n Step 2), place the screws through
CB3 Screw Guide and into the plate. Ti ghten until secure.
Ens ure that each screw is completely s eated into the plate.
Revision 01
Removal of screwdriver blade
Remove the screwdriver blade from the s crew by l ifting the
CB3 Screw Guide and rocking the s crewdriver blade back a nd
forth.
