KLS Martin group L1 Rib Gebrauchsanweisung Seite 44

Catalogue
Name
number
50-990-00-07 Angul us 2 Angled Screwdriver, complete
50-991-20-07 ma xDri ve Blade, 2.0 / 2.3 mm, 10 mm
50-991-20-71 ma xDri ve Blade, 2.0 / 2.3 mm, 10 mm, s terile
50-996-07-07 Twi s t Drill 1.5x15x7 mm, Angul us 2, 1pc
In addition to standard instruments such as holding forceps, screwdrivers etc., the use of which is self-
explanatory, special instruments are available, the use of which is explained below:
Depth gauge
One of the following depth gauges is available to ensure that the rib is sufficiently thick (at least 7 mm).
Implanting the screws is not recommended if the bone is thinner than 7 mm.
Adjustable Tri Color Depth Gauge 24-015-50-07
Pus h the sliding button to extend the working ends a round the
ri b. The ti p is spring loaded and will cl ose down on the rib
a utomatically when released. After releasing the button read
the di splay window.
Rib has adequate thickness.
Caution: only use with a screw guide.
Do not use.
The pl acement of s crews i nto bone less than 7 mm i s not
recommended.
44
Fixed Depth Gauge 24-015-51-07
Adequate
Caution
Do not use
The Fi xed Depth Gauge provides a s imple method of
mea suring ri b minimum thickness.
If the Fi xed Depth Gauge fits over the ri b, use the Adjustable
Ga uge to determine i f s crew placement is possible. If the Fixed
Depth Gauge does not fit over the ri b, then the ri b thickness is
grea ter than 7 mm. This thickness is a dequate for placement
of s crews with or wi thout the Screw Guide controlling the
a ngle of i nsertion.
L1 Rib
Instructions for Use
Revi sion 01
