Some of the plate designs are available in various lengths.
The special designs allow more screws per rib fragment to be placed than in conventional plate designs.
The L1 rib plates have a locking thread which enables fixed-angle restoration.
The L1 rib plates have different color coding depending on the plate thickness:
Figure
The available L1 rib plates are listed below with the catalogue numbers:
Catalogue
Name
number
24-015-20-71 L1 Ri b X-Pl ate, 10-hole, 1.5 mm, 55 mm l ength, sterile
24-015-22-71 L1 Ri b X-Pl ate, 20-hole, 1.5 mm, 106 mm l ength, sterile
24-015-25-71 L1 Ri b X-Pl ate, 32-hole, 1.5 mm, 163 mm l ength, sterile
24-015-26-71 L1 Ri b X-Pl ate, 32-hole, 2.0 mm, 163 mm l ength, sterile
24-015-29-71 L1 Ri b Spar Plate, 14-hole, 1.5 mm, 90 mm l ength, sterile
24-015-30-71 L1 Ri b Universal Plate, 14 Hole, 1.5 mm, 103 mm l ength, sterile
24-015-31-71 L1 Ri b Ta bbed Plate, 16-hole, 1.5 mm, 85 mm l ength, s terile
24-015-32-71 L1 Ri b Solid Plate, 16-hole, 1.5 mm, 85 mm l ength, s terile
24-015-35-71 L1 Ri b Solid Plate, 20-hole, 1.5 mm, 102 mm l ength, sterile
24-015-36-71 L1 Ri b Solid Plate, 20-hole, 2.0 mm, 102 mm l ength, sterile
4.1.1.2 Screws
Possible risk of injury to the patient in case of incompatible fastening elements!
The L1 rib plates may not be combined with incompatible osteosynthesis screws under any circumstances.
40
Instructions for Use
Plate thickness Color
1.5 mm gol d
2.0 mm grün
