BICWCO02 (Published) Book specs- Dates: 20070515 / 20070515 / 20070515 Lang: ENG01 Applic: CWS
1.1. Controls on Mark VI Non-Tilting Washer-extractors
Refer to other parts of this document
basic function of individual controls. Don't use this document as instructions for operating the
machine.
Where are the Controls?
1.1.1.
The essential controls for normal operation are located on the front control panel
Additional controls and connections are located elsewhere on the machine, as described here.
Figure 1: Locations of Controls
Front Left View
.
Where do I Connect the Data Storage Device?
1.1.2.
The microprocessor box in the upper rear corner of the machine left side panel (see
contains a DIN-type connection for serial communications. Use this connection, labelled as
shown in
Figure
2, with a serial data transfer device to save or restore machine programming and
configuration memory.
(Section 1.1.2
through
Section
Rear View
7
Chapter 1. Controls
1.1.4) for the location and
(Figure
1).
Legend
A.
Microprocessor control
box (68036F_B shown)
B.
Control panel
C.
Manual supply flush
button
D.
Hydraulic pressure gauge
for loading door
E.
Air pressure gauge for tilt
system (behind lower rear
panel)
Figure
1)
PELLERIN MILNOR CORPORATION
