Controls; Physical Controls; Figure 1 Control Panel; Master Power Switch - Milnor MWF45Z8 MilTouch Benutzerhandbuch

2 Controls

BNWUUO03 / 2020403
2.1

Physical Controls

The following figure shows how the control panel appears on your machine.
Figure 1. Control Panel

Master power switch (

trol system.
Remove power from the control system.
Energize the control system.
4
BNWUUO03
BNWUUO03.R01 0000267801 C.2 A.5 A.10 9/16/20 9:06 AM Released
) — This switch energizes and removes power from the con-
0000267770 A.5 9/29/20 9:34 AM
Legend
A... Touchscreen for the
MilTouch™
controller
B... Master power
switch
C... Door unlock button
D... USB port
Pellerin Milnor Corporation
Released
