A1 TCCE TECHNICAL DATA
Technical data MODEL TCCE version
cooling only with standard fans
Nominal cooling capacity (*)
E.E.R. (*)
E.S.E.E.R. (*)
Sound pressure level (*) (**)
Sound power (***)
Refrigerant circuits
Scroll compressor / steps
R407C refrigerant charge/ (POE)
polyolesters oil charge (****)
Fans
Fans motors installed power
Fan nominal air flow
Max E.S.P.
Max RPMs
Evaporator nominal water flow (*)
Evaporator nominal pressure drops (*)
Evaporator water contents
Dimensions
Length
Height
Depth
Empty weight (TCCE with no accessories)
Electrical data
Power supply
Total absorbed power (*) (*****)
Nominal current
Maximum current
Starting current
MODEL TCCE with CC accessory or LOW AMBIENT
Fans
Fans motors installed power
Electrical data
Total absorbed power (*)
Nominal current
Maximum current
Starting current
(*) At the following conditions: condenser
inlet air temperature 35°C; chilled water
temperature 7°C; water ∆t at the evaporator
5°C.; max. E.S.P (E.E.R. refers to the
version without accessories).
(**) Sound pressure level in dB(A) in
reference to a distance of 5 metres from
the unit in an open space (Q = 1), with
perfectly ductable fans.
(***) Total sound power level in dB (A)
based on measurements made in
accordance with the UNI EN-ISO 3744 and
Eurovent 8/1.
130
kW 30,1
2,49
2,87
dB(A) 54
dB(A) 76
n. 1
n. 1 / 1
kg 8,0/3,3
n. 2
kW 1,1
3
m /h 8.500
Pa 145
rpm 688
3
m /h 5,2
kPa 20
l 2,8
mm 1.855
mm 1.915
mm 910
kg 543
V-ph-Hz
kW 12,1
A 23,2
A 26,5
A 178
130
n. 2
kW 1,55
kW 14,6
A 24,3
A 27,6
A 179
(****) Indicative value: the correct value can
be found on the machine rating plate.
(*****) Total power consumption is
calculated considering a part to be
subtracted in accordance with prEN 14511,
equal to P =∆p*Q/0,3, where ∆p and Q
sottr.
are respectively the available static
pressure and the flow rate, in nominal
conditions, of the fans for the machine in
question.
123
135 140 150
34,5 37,3 47,2
2,38 2,50 2,52
2,80 2,94 2,91
59 57 57
81 77 76
1 1 1
1 / 1 1 / 1 1 / 1
8,5/6,6 9,5/6,6 12,0/8,0
2 2 2
2,2 2,2 2,2
11.000 15.000 15.000
155 125 125
764 648 582
5,9 6,4 8,1
20 21 23
3,3 3,9 4,9
1.855 2.355 2.355
1.915 1.915 1.915
910 1.010 1.010
562 667 770
400-3+N-50
14,5 14,9 18,7
28,6 29,9 36,2
31,8 31,8 39,8
180 180 220
135 140 150
2 2 2
2,6 3,1 3,1
18,3 19,5 23,2
29,8 32,3 38,4
33,0 34,9 42,0
181 183 222
N.B.:
The E.S.P and electrical power absorbed
data for the motor-driven pumps relative to
the PUMP and TANK&PUMP accessories
can be found on pages 21, 22 and 23.
ENCLOSED DOCUMENTS
160 270
59,4 66,3
2,59 2,30
3,08 3,42
60 64
79 83
1 1
1 / 1 2 / 2
15,0/8,0 18,0/6,6x2
2 2
3,0 4,4
17.000 20.000
150 155
675 740
10,2 11,4
25 27
6,3 6,3
2.355 2.355
1.915 1.915
1.010 1.010
781 857
22,9 28,8
43,2 56,4
49,6 63,2
277 212
160 270
2 2
5,1 5,8
29,9 36,3
47,3 59,1
53,7 65,9
281 215
