COMPACT PIEZO LED
NOTE: If necessary to reach the immunity test
level, the distance between the transmitter
antenna and COMPACT PIEZO LED can be
reduced to 1 m. The test distance of 1 m is
allowed by IEC 61000-4-3.
7 TROUBLESHOOTING
7.1 Diagnostics
COMPACT PIEZO LED is provided with a diagnostic circuit that allows the detection of
malfunctions and viewing of their type via the two-coloured green/red LED on the module.
LED
green lit
green and red flashing alternately
green and red lit
green lit and red flashing
LED
green lit
green and red lit
green and red flashing alternately
red steadily lit
34
Appliance Powered Without Pedal Consent
Appliance Powered With Pedal Consent
WARNING: Portable RF communication
equipment (including peripheral devices such
as antenna cables and external antennas)
must not be used closer than 30 cm to any
part of the COMPACT PIEZO LED device,
including the cables specified by the
manufacturer. Otherwise, there may be
a performance degradation of these
appliances.
Description
Correct operation.
Incorrect installation:
• potentiometer not connected.
Indicates that the general protection was ac-
tivated during the last cycle.
Indicates that the failed tuning scan protec-
tion was activated during the last cycle.
Description
Correct operation.
Current limiter in operation.
Incorrect installation:
• Power supply too low;
• Power supply too high;
• Potentiometer not connected.
General protection tripped:
• Handpiece not connected to the cord;
• Tuning circuit malfunction;
• Broken wire in the cord;
• Faulty Handpiece.
