COMPACT PIEZO LED
4

INSTALLATION

COMPACT PIEZO LED, in order to operate
must be connected to a dental unit.
The dental unit mechanically houses the pilot
module, supplies power to the module, and
supplies water to cool the handpieces and in-
serts.
The dental unit to which COMPACT PIEZO LED
is connected must be a medical device that
complies with general and applicable product
regulations for the specific category of den-
tal unit, and in general, satisfy the following
standards:
4.1 Safety Requirements During Installation
WARNING: Risk of explosion.
The appliance cannot operate in
environments where there are saturated
atmospheres of flammable gases (aesthetic
mixtures, oxygen, etc.).
WARNING: Install the appliance in a safe
place protected from impact or accidental
water or liquid spray.
WARNING: Do not install the appliance
above or near sources of heat. Arrange
during installation for a suitable circulation of
air around the appliance.
CAUTION: The water hose of the scaler
handpiece cord must be directly connected
to the dental unit cold water circuit.
CAUTION: The voltage of the power
supply line to which the appliance is
connected must be compatible with the
technical specifications (see
page 34)
and envisaged connection layout.
CAUTION: For the correct power supply,
use a power adapter compliant with IEC/EN
60601-1 having the following characteristics:
• 24 V~ 50/60 Hz or
• 32 V with minimum power 40VA.
12
• ISO 7494 Dentistry – Stationary dental
• ISO 60601-1 Medical electrical
which COMPACT PIEZO LED is connected
satisfies the specified requirements.
the connector of the red wire and black wire
of the scaler handpiece cord (see Figure 4 on
page 19).
wires of the scaler handpiece cord (see Figure
4 on page 19) together with other cables.
required for the power supply, use wires with
a suitable wire gauge, for example 1.5 mm
changes to this appliance.
manufacturer of the dental unit on which
the COMPACT PIEZO LED module has been
installed is responsible for ensuring the
product and entire system remain compliant
with IEC/EN 60601-1 in force".
Chapter 7 on
handpiece to its cord, check that the electrical
contacts are perfectly dry, on both parts. If
necessary dry them with compressed air.
units and dental patient chairs;
equipment – Part 1: General
requirements for basic safety and
essential performance.
CAUTION: Check that the dental unit to
CAUTION: Do not invert the position on
CAUTION: Do not wire the red and black
CAUTION: If long connections are
CAUTION: It is prohibited to make any
WARNING: The installer or
CAUTION: Before connecting the
.
