COMPACT PIEZO LED
4.3.8.5 Layout E
The power supply (24 V~ 50/60 Hz ±10% or 32 V
pedal.
The power is regulated by a 4.7KΩ linear potentiometer (see Figure 9 on page 22).
4,7 KΩ linear
potentiometer
The
potentiometer is
not included in
the supply
39 kOhm 1/8 W 1%
4.3.8.6 Layout F
The power supply (32 V
consent is provided by the pedal. The power is regulated by a 2.2KΩ linear potentiometer (see
Figure 10 on page 22).
2,2 kOhm
linear potentiometer
22
Fuse holder, fuse and pedal
are not included in the
Mectron supply
Yellow
Pedal
Yellow
resistance
1 2 1 2
9 16
8 7 6 5 4 3 2 1
Figure 9 – Layout E
±10%) is provided by contact with the instrument tray and positive
Pedal
Yellow
Instrument tray
Yellow
1 2
Figure 10 – Layout F
±10%) and consent are provided by the
Power supply
24 V ~ 50/60 Hz or
Fuse
32 V
Minimum 40VA
T 2 A
Scaler handpiece cord
Fuse holder, fuse and pedal
are not included in the
Mectron supply
Fuse
Power supply
T 2 A 32 V
Minimum 40VA
Scaler handpiece cord
