mectron Compact Piezo LED Installationsanleitung Seite 34

COMPACT PIEZO LED
Power
Solenoid valve control output
Water supply
Handpiece LED system
Protections of the APC Circuit
Diagnostics
Operating Conditions
Transport and Storage Conditions
Altitude
Dimensions and Weight
Table 8 – Technical Data
26
Adjustable depending on the type of in-
stallation.
24V , 2.5W
Adjustable depending on the type of in-
stallation.
Working pressure from 1 to 6 bar.
Adjustable in accordance with the indica-
tions provided by the manufacturer of the
dental unit.
White LED light power risk free according
to standard IEC/EN 62471.
Missing handpiece;
Breaking wire cord;
Insert not correctly tightened or broken;
Grounding protection tripped.
Two-coloured green and red LED warning
light (see Chapter 7.1 on page 34)
from 10°C to 40 °C
Relative humidity from 30% to 75%
Air pressure P: 800hPa/1060hPa
from -10 °C to 60 °C
Relative humidity from 10% to 90%
Air pressure P: 500hPa/1060hPa
lower than or equal to 2000 metres
71x46x34 mm
120 g
