COMPACT PIEZO LED
Pin
1 Reserved
2 RIS
3 TX
4 RX
5 Valve
6 Power Control
7 Pedal -
8 +Vdc
Table 5 – M1 Connector Pin-Out.
M2 Connector Pin-Out
Pin
1 Vout handpiece
2 Neutral
Table 6 – M2 Connector Pin-Out.
14
M2
1
Figure 3 – Module connectors.
M1 Connector Pin-Out
Signal
Signal
M1
2 1 2 3 4 5 6 7 8
16 15 14 16 15 14 13 12 11 10 9
1 2
M3
Pin
9 Bypass capacity
10 GND
11 Pedal +
12 Power Selection
13 AC In
14 AC/DC In
15 GND
16 Reserved
M3 Connector Pin-Out
Pin
1 LED A
2 LED K
Table 7 – M3 Connector Pin-Out.
Signal
Signal
