Bipolar Sealing System marSeal5 plus/ - Maryland
Instructions for Use
Illustration
Accessory Components for the Instrument
Illustration
Accessory Components for Cleaning
The blade holder with integrated blade for tissue separation is a consumable. It is available both sterile and
non-sterile. It is not included in the scope of delivery of the instrument and must be ordered separately, see
section 7.2 "Consumables", page 89.
5.1.1
Structure, Functionality and Performance Characteristics
The bipolar sealing instrument marSeal5 plus is intended exclusively for use with the electrosurgical unit
maxium® (REF 80-042-00-04, REF 80-042-02-04 and REF 80-042-04-04, type ME 402) from software version
V3.423, or new developments by the manufacturer. The IQ connector of the marSeal5 plus can be
connected to the bipolar socket B 1 or B 2 of the electrosurgical units maxium®. The current type
SealSafe® IQ is selected automatically. It can be used exclusively with IQ instruments (Plug & Play)!
Vessels up to a maximum diameter of 7 mm can be permanently sealed. In the case of large vessels, double
sealing applied side by side is recommended. The vessel can then be cut in the middle using the integrated
blade.
Revision 06
The combination of mechanical pressure (p) and high-frequency current-induced
coagulation (I) creates a reliable and permanent sealing zone on arteries, veins or
tissue bundles. It is of vital importance that the pressure is maintained at a
constant level for the entire duration of the application.
Designation
Sterile blade holder 450 mm, single-use, sales unit =
10 pcs
Sterile blade holder 370 mm, single-use, sales unit =
10 pcs
Sterile blade holder 230 mm, single-use, sales unit =
10 pcs
Designation
Cleaning tool
Flushing adapter set consisting of:
Flushing adapter with Luer lock connection and
silicone hose for the outer tube
Flushing adapter with Luer lock connection and
silicone hose for the inner tube
65
