Instructions for Use

6.10 Blade Holder

6.10.1 Inserting the Non-Sterile Blade Holder

Danger of infection from improper handling!
Improper sterilization and non-sterile handling can lead to serious health hazards to patients.
• Sterilize non-sterile blade holder before each application.
The instrument with the inserted non-sterile blade holder can be sterilized when fully assembled.
Danger of infection and injury from sharp blades!
When the tubular shaft is dismantled, the integrated blade (2) can be pushed through the tubular shaft
and out of the open jaw part by accidentally pressing on the rear end of the blade holder (1).
• Avoid contact with the sharp blade (2)!
The working method must at all times be carried in such a manner that no contamination of the sterile
surgical gloves and the sterile blade holder occurs.
Revision 06
1 Outer tube
2 Inner tube
3 Blade Holder
• Slide the blade holder (3) into the inner tube (2)
from the rear.
• If necessary, turn the blade holder slightly in the
last third until it can be pushed into the jaw part.
85
