Reflex Servitec 35 Originalbetriebsanleitung Seite 43

ER Code Alarm
06 Make-up time
07 Make-up cycles
08 Pressure measurement
10 Maximum pressure
11 Back-up volume
12 Filling time
13 Filling volume
14 Discharge period
15 Make-up valve
16 Power failure
Stop ˃ 4 hours
19
20 Maximum make-up quantity Set value exceeded.
21 Maintenance recommended Set value exceeded.
24 Water treatment
25 Datalogger
26 Conductivity measurement
27 Conductivity exceeded
29 Communication
30 I/O module fault
31 EEPROM defective
32 Undervoltage
33 Adjustment parameter
34 Main board communication
faulty
35 Digital input voltage faulty
36 Analogue input voltage
faulty
37 Input voltage MKH1
39 Pressure jumper
40 Level jumper
41 Replace battery
42 Bus module
Causes
• Set value exceeded.
• Water loss in the system.
• Make-up line not connected.
• Make-up rate insufficient.
Continuous water loss in the system.
Controller receives incorrect signal.
For "Magcontrol" setting only.
• Set value exceeded.
"With water meter" must be activated in
the Customer menu.
• Set value exceeded.
• Severe water loss in the system.
Set value for the maximum filling duration
has been exceeded.
Set value exceeded
• Set value exceeded.
• "DC" degassing line closed.
• Dirt trap clogged.
Contact water meter measures without
make-up request.
No power.
Longer than 4 hours in stop mode.
• Water capacity set value exceeded.
• Time interval for replacement of the
cartridge exceeded.
• No SD card inserted
• The SD card is write-protected
• The SD card has not been recognised
Measured value outside the measuring
range.
• Set value exceeded.
• Cartridge capacity expired.
Master-slave communication or master
controller faulty
• I/O module defective.
• Connection between option card
and controller faulty.
• Option card defective.
• EEPROM defective.
• Internal calculation error.
Supply voltage not achieved.
EEPROM parameter memory defective.
• Connecting cable defective.
• Main board defective.
Short-circuit of input voltage.
Short-circuit of input voltage.
Short-circuit of input voltage.
Main board jumper does not match
configuration.
Main board jumper does not match
configuration.
Battery discharged.
Bus module was not detected.
Vacuum spray degassing — 18.12.2019-Rev. A
Remedy
• Check set value in the Customer or Service menu.
• Check water level.
• Connect make-up line.
• Check set value in the Customer or Service menu.
• Seal the leak in the system.
• Check/connect the plug connection at the pressure
transmitter.
• Check the cable for damage.
• Check the pressure sensor.
• Check set value in the Customer or Service menu.
• Set the actuating pressure of the safety valve.
• Check set value in the Customer or Service menu.
• Check the water loss and correct, if necessary.
• Check set value in the Customer or Service menu.
• Check the water loss and correct, if necessary.
• Check set value in the Customer or Service menu.
• Check the water loss and correct, if necessary.
• Check set value in the Customer or Service menu.
• Open the degassing pipe.
• Clean the dirt trap.
Check the 2-way motorized ball valve (WV) for leaks.
Connect to power supply.
Set the controller to Automatic mode.
Reset the "Make-up quantity" meter in the Customer menu.
Carry out maintenance.
• Replace the softening cartridge.
• Insert a FAT16 or FAT32-formatted SD card.
• Disable write-protection.
• Check set value in the Customer or Service menu.
• Check the sensor and cabling.
• Check set value in the Customer or Service menu.
• Replace the cartridge.
Check connection.
• Replace the I/O module.
• Check the connection between option card and controller.
• Replace the option card.
Inform Reflex Customer Service.
Check power supply.
Inform Reflex Customer Service.
Inform Reflex Customer Service.
Check the wiring at the digital inputs (water meter, for example).
Check the wiring at the analogue inputs (pressure/conductivity).
Check the wiring at the 2-way motorized ball valve.
Check jumper position.
Check jumper position.
Replace backup battery in operating unit.
• Check the set values.
• Check the bus module.
Controller
Alarm reset
"OK"
"OK"
"OK"
"OK"
"OK"
"OK"
"OK"
"OK"
"OK"
–
–
"OK"
"OK"
–
–
–
"OK"
–
–
–
–
–
–
–
–
–
–
–
–
–
English — 43
