Parameter Setting
Softening (only if "Water treatment with Softening")
Shut off make-up No
Hardness reduction 8°dH
Soft water capacity 0 Litres
Cartridge replacement 18 months
Desalination (only if "Water treatment" with Desalination")
Conductivity monitoring No
Shut off make-up No
Hardness reduction 8°dH
Soft water capacity 0 Litres
Cartridge replacement 18 months
Next maintenance 12 months
Volt-free contact YES
Service menu
Parameter Setting
Make-up
Pressure differential, 0.1 bar
"NSP" make-up
Pressure differential, filling 0.2 bar
pressure PF – P
0
Maximum filling duration 10 h
Degassing
Idling times between 10 hours
degassing intervals
Number of degassing n = 8
cycles for each interval
Daily start 08:00 h
10.1.4 Degassing programmes – overview
You can choose between 3 degassing programs:
Continuous degassing
• Usage:
– For device commissioning.
– For degassing of the water after a device or facility system repair.
• Activation:
– An automatic activation occurs after completion of the start routine
during initial commissioning.
• Times:
– The time can be set in the Customer menu.
– The default setting is 24 hours. Subsequently, the system
automatically switches to Interval degassing.
In continuous degassing, the degassing cycles are sequentially performed for 24
hours.
Interval degassing
• Usage:
– For continuous operation of the device.
• Activation:
– Automatic activation occurs after the ending of continuous
degassing.
• Times:
– 8 degassing cycles per interval is set in the Service menu.
– After 8 intervals there is an idling time of 12 hours.
– The times for interval degassing are stored in the Service menu.
– The daily start of interval degassing is at 8:00 a.m.
Remarks
In the case of soft water
residual capacity = 0
= Target – Actual
Attainable water capacity
Replace cartridge
In the case of soft water
residual capacity = 0
= Target – Actual
Attainable water capacity
Replace cartridge
Time left to the next due
maintenance
Only the messages marked in
the "Messages" list
Remarks
Only Magcontrol
Only Magcontrol
Only Magcontrol
Idling times between the
degassing intervals
Number of degassing cycles in
one interval
Start of the daily degassing
intervals
Vacuum spray degassing — 18.12.2019-Rev. A
Interval degassing is preset in the customer menu as the default setting.
Make-up degassing
• Usage:
– For gas-rich water from the make-up.
– For summer operation when the circulating pumps of the facility
system are shut down,  9.1.4 "Summer operation",  39.
– If the facility system water is not to be degassed.
• Activation:
– Automatic activation occurs at every water make-up.
• During continuous degassing.
• During interval degassing.
• Times:
– The make-up water is degassed for as long as it is supplied,  10.1.1
"Customer menu",  39.
 Note!
Manual activation of the degassing program takes place in the customer
menu.
10.1.5

Setting degassing programmes

1. Press "Settings".
– The controller switches to the setting area.
2. Press "Customer >".
– The controller opens the Customer menu.
3. Press "Degassing >".
– The controller switches to the selected area.
– Use the scroll bar to navigate "up" and "down" through the list.
4. Press "(012) Degassing programme".
– The controller opens the list of degassing programmes.
Controller
English — 41
